3.x.x Firmware Support



GENERAL DESCRIPTION



KEY PRODUCT FEATURES

  1. ESP32 NINA W106 Ublox , ESP32 WROOM-32UE and ESP32 WROOM-32E (ESP32 D0WD ECHO V3)
  2. ESP32 WROOM-32D and ESP32 WROOM-32U (ESP32 D0WD )
  3. ESPrtk module used to transmit wireless GNSS data in high precision positioning applications.
  4. ESPrtk is geared towards the ability to use high quality, independent, wireless and low cost platforms.
  5. Users can access and control ESP32 chip internal hardware.
  6. User update firmware.
  7. Multi-connection.
  8. Control and high speed real-time data processing.
  9. Protect device – Encrypt data.
  10. Automation of connections .
  11. Energy / Power / Speed / Hardware / Device manager.



  1. MQTTTM – NTRIPTM – NTRIP_CASTER TM – TCP/UDPTM – RADIOTM bridge for RTK position.
  2. Basestation RTK, Rover RTK.
  3. RTCM data – NMEA data – UBX data – SKYTRAQ data
  4. WIFI – Bluetooth Classic – Bluetooth BLE.
  5. Ethernet module ENC28J60 (10Mbs)- W5500 (100Mbs) ,W5110. W5XXX
  6. LoRa module 1276-1277-1278-1279 .
  7. SD Card – OLED Display SSD1360/SH1106 – IMU MPU9250 – NEOPIXEL led.
  8. UART Configure – ESPrtk command.
  9. WEB Configure – UI WEB interface.
  10. Encrypt : Bitwise, AES , WAP, WAP2. SSL.
  11. Navspark : NS-HP-BD / -GL / -GN. PX1120R , PX1122R
  12. Ublox : NEO , LEA, M8P, F9P, F9K,F9H.
  13. Hemisphere: Eclipse P307 .
  14. NVS Technologies:NV08C-RTK .
  15. Swift : Piksi Multi .
  16. Trimble , Topcon RTK receiver .
  17. Support SIMCom 2G SIM800 + SIM900 series (SIM800A, SIM800C, SIM800L, SIM800H, SIM808, SIM868 , SIM900A, SIM900D, SIM908, SIM968).
  18. Support SIMCom 3G SIMCom WCDMA/HSPA/HSPA+ Modules (SIM5360, SIM5320, SIM5300E, SIM5300E/A) SIMCom LTE Modules (SIM7100E, SIM7500E, SIM7500A, SIM7600C, SIM7600E) SIMCom SIM7000E/A/G CAT-M1/NB-IoT Module.
  19. Support Quectel 3G Quectel BG96 Quectel M95 Quectel MC60.
  20. Support U-blox 2G, 3G, 4G, and LTE Cat1 Cellular Modems (many modules including LEON-G100, LISA-U2xx, SARA-G3xx, SARA-U2xx, TOBY-L2xx, LARA-R2xx, MPCI-L2xx) u-blox LTE-M/NB-IoT Modems (SARA-R4xx, SARA-N4xx, but NOT SARA-N2xx).
  21. Support U-blox 2G, 3G, 4G, and LTE Cat1 Cellular Modems (many modules including LEON-G100, LISA-U2xx, SARA-G3xx, SARA-U2xx, TOBY-L2xx, LARA-R2xx, MPCI-L2xx) u-blox LTE-M/NB-IoT Modems (SARA-R4xx, SARA-N4xx, but NOT SARA-N2xx).
  22. Support Digi XBEE_Cellular 2G/ 3G /LTE CAT 1 / LTE-M
  23. Support Script AT command for GSM/LTE/ 2G,3G,4G sim.
  24. Support Low Speed Stream + UART Repeater ( RTK Offline ).
  25. Antenna + Position Manager.
  26. F9P for TOPCON/TRIMBLE + AGOPENGPS.



FREE

$0/PER UNIT
  • Price : 0 dollar
  • Verify ID
  • Unlimited days use
  • Main functions
  • 10x option
  • Email support

FULL

$50/PER UNIT
  • Price : 50 dollars
  • Verify ID
  • Unlimited days use
  • Full functions
  • Full option
  • Email support + Notification

Buy ESPrtk Key Activate Firmware 3.x.x

+Unlimited days use ESPrtk 3.x.x . +Full functions ESPrtk 3.x.x . +Full option ESPrtk 3.x.x . +Support via Email .

$50.00

  • Email to address : contact@esprtk.com
  • Letter title : Purchase request
  • Hello,I need to get the activation file. Owner name : [Your Name] . On 03/03/2020 , (d/m/y) I used my paypal/visa/mastercard account named [ Your paypal/visa/mastercard’s Name ] to send 50 dollars to paypal account [phungthaison96@gmail.com] with the request to buy 1 KEY files (price is 50 dollars for 1 device) for the REQUEST files below. Benefit package : FULL . The REQUEST file number in the directory: 1 Files. (And attach your Request_Folder.zip file .)

Download ESPrk datasheet , Arduino Code , Documents

Go to this page to download all ESPrtk document : ESPrtk documents
